High-flow High-siab Blower
Thaum cov txheej txheem kev lag luam xav tau ob qho tib si tus nqi ntws siab thiab kev kub siab ib txhij, cov qauv tshuab tshuab ib txwm muaj feem ntau ntsib qhov "dav-kev lag luam siab- tawm qhov teeb meem"- nce ntws feem ntau txhais tau hais tias lub siab siab, thiab lwm yam. Loj -kev kho dej khib nyiab, kev thauj khoom, kev ziab khaub ncaws, thiab kev tsim hluav taws xob xav tau cov kev daws teeb meem uas kov yeej qhov kev txwv ntawm lub cev.
WinCend High-Flow High-pressure Blower Series ua tiav kev sib tw hauv ob qho tib si ntws thiab siab los ntawm kev tsim kho tshiab ntau-theem compression thev naus laus zis thiab cov tshuab ntse sib txuas. Nws muab scalable, muaj txiaj ntsig zoo, qis -kev kho pneumatic fais fab kev daws teeb meem rau loj- nplai kev lag luam thoob ntiaj teb.
WinCend siab-siab blowers feature patented mix-flow design that ingeniously combines the high-flow features of axial-flow blowers with the high-pressure capabilities of centrifugal blowers. Airflow yog thawj zaug nrawm dua thiab ua ntej lub zog los ntawm axial-flow theem ua ntej nkag mus rau theem centrifugal rau compression ntxiv. Qhov ob -theem kev sib koom ua ke nce ib qho -unit efficiency mus rau 78-85%, ua tau zoo tshaj cov qauv tsim.
Qhov sib xyaw- ntws impeller yog qhov tseeb-milled los ntawm ib qho ntawm aerospace- qib aluminium alloy, es tsis yog siv cov txheej txheem vuam los yog cov txheej txheem casting. Qhov no ua kom muaj kev sib npaug zoo meej thiab kev ua haujlwm zoo thaum lub sijhawm siab -kev sib hloov ceev (txog 12,000 rpm). Cov txheej txheem tsim khoom no ua rau lub impeller tuaj yeem tiv taus qhov nrawm dua peripheral, yog li ua tiav qhov sib piv siab dua.
Rau cov ntawv thov uas yuav tsum tau muaj kev kub ntxhov siab heev, WinCend muaj kev teeb tsa ntau -theem compression systems. Los ntawm cascading 2-4 theem compression ntawm ib qho kev sib tw, qhov nce siab ntawm ib theem ua rau lub qhov hluav taws xob zaum kawg. Precision-engineered interstage diffusers xyuas kom cov kev hloov pauv hloov tau yooj yim, txo qis kev poob siab.
Multi-theem systems feature xaiv qhov kev ua kom txias txias, siv ua- hauv cov khoom siv hluav taws xob los tswj cov roj kub. Qhov no tiv thaiv compression piv txwv los yog downstream khoom puas tsuaj tshwm sim los ntawm qhov kub thiab txias nce. Qhov kev tsim no tshwj xeeb tshaj yog haum rau cov txheej txheem roj compression thiab siab -kub ziab daim ntawv thov.
Txhua qhov loj- nplai kev lag luam muaj qhov tshwj xeeb pneumatic. WinCend muab rau hauv -qhov tob engineering customization cov kev pabcuam:
1. Kev xaiv cov khoom siv:
Muaj ntau yam khoom siv raws li cov yam ntxwv nruab nrab, suav nrog cov qauv carbon steel, 304/316 stainless hlau, duplex stainless hlau, titanium alloys, lossis cov txheej txheem sib xyaw.
2. Sealing Solutions:
Rau cov pa phem, flammable, lossis muaj txiaj ntsig zoo, peb muab cov kev xaiv xws li cov roj foob qhuav, cov ntsaws ruaj ruaj labyrinth, lossis cov hlau nplaum sib nqus, nrog cov nqi xau raws li API 682 tus qauv.
3. Kev tiv thaiv tawg & ntawv pov thawj:
Ua tau raws li ATEX, IECEx, lossis North American Class/Division system explosion tiv thaiv cov cai, tsim nyog rau ib puag ncig txaus ntshai xws li petrochemical nroj tsuag thiab thee mines.
4. System Integration:
Kev xa cov kev daws teeb meem tag nrho suav nrog cov tshuab tshuab, pom cov tshuab, cov twj tso kua mis, cov tshuab tswj, thiab kev ntsuas kev ua haujlwm.
High-flow siab-pressure blower Application Industries:
1. Kev kuaj huab cua
2. Cov khoom siv tshem tawm plua plav
3. Cov khoom siv roj teeb lithium
4. Cov khoom siv kho mob
5. Cov khoom siv tu
6. Kev lag luam hluav taws xob
7. Cov khoom siv tshuaj tua kab mob
8. Cov khoom siv semiconductor
9. Cov khoom siv hluav taws xob photoelectric
10. Cov khoom siv tsis siv neeg
Cim npe nrov: high-flow siab-siab blower, Tuam Tshoj siab-flow siab-siab blower manufacturers, hoobkas
